U SHAPE PAPER STRAW MAKING MACHINE

1650000 INR/Set

Request To Call Back Send Inquiry

Price And Quantity

Model	PAPER STRAW MACHINE
Technical Parameter		Control System
Number of paper	3 layers(4 layers custom)	PLC Controller	Delta
Max-diameter	20mm	Man-machine interface	Weinview touchscreen
Min-diameter	5mm	Program edition	JS-NC5.0
Min-thickness	0.5mm	Servo system	Delta
Min length	90mm	Actuator	CHNT
Output Speed	100m/min	Max-length	1200mm
Rewinding noses	Two noses/one belt	Signal component	Airtac
Cutting way	10blades pneumatic	Synchronism control	Synchronous belt
Length fixation	Encoder	Synchronism tracking cutting system	Servo synchronized Tracking System
Operator	1 person	Outfit assemble
Way of shaft fixing	Pushing	Tube holder	Have
Speed control	Servo	Belt angle adjusting	Hand wheel adjustment
Power input	3*380v(can be customized)	Belt tension adjusting	Hand wheel adjustment
Size(mm)		Stop when paper break(bottom)	Auto
Mainframe size:L*W:H	351112651800mm	Glue way	Glue roller(single and double)
Area space:L*W	17000*6000mm	Lubrication	Electric roller
Wheel hub diameter	215mm	Paper tension control	Constant tension control
Wheel hub height	125mm	Paper stand	Auto splicer paper
Min-Tread	320mm	Belt	Sailcloth
Max-Tread	500mm	Enclosed Component
Total Weight	1900kgs	Mandrel	1 set
Drive System		Belt	1 pc
Main power	6.0KW(Servo motor)	Useful tool	1 set
Max rotate speed of wheel hub	200r/min	Air compressor	No
Output torque	68N.M
Drive of wheel hub	2 Wheel drive
